格蘭湯普森偏振器
 |
 |
|
| 材料： | α-BBO, Calcite | |
| 波長范圍： | α-BBO: 190-1100 nm, Calcite: 350-2300 nm | |
| 消光比： | Calcite:<5x10 -5 ; α-BBO:<5x10 -6 |   |
| 平行度： | < 2" | |
| 表面質量： | 20-10 | |
| 光束偏差： | 典型值: <3 ', 高精度: <3" | |
| 平面度： | λ/4@633nm | |
| 損壞閾值： | > 200 MW/cm 2 | |
| 涂層： | Single MgF2 | |
| 安裝： | Black Anodized Aluminium | |
| Part No. | L/CA | Extinction Ratio | Angular Field(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1(mm) |
| GMP6006 | 1.6 | <5x10 -6 | >15° | 5 | 15 | 14 |
| GMP6008 | 7 | 25.4 | 17 | |||
| GMP6010 | 9 | 25.4 | 21 | |||
| GMP6012 | 11.4 | 25.4 | 26 | |||
| GMP6015 | 13.5 | 30 | 31 | |||
| GMP6020 | 18 | 38 | 40 |
| Part No. | L/CA | Extinction Ratio | Angular Field(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1(mm) |
| GMP7106 | 2.5 | <5x10 -6 | 14°-16° | 5 | 15 | 18 |
| GMP7108 | 7 | 25.4 | 23 | |||
| GMP7110 | 9 | 25.4 | 28 | |||
| GMP7112 | 11.4 | 25.4 | 35 | |||
| GMP7115 | 13.5 | 30 | 41 | |||
| GMP7206 | 3 | <5x10 -6 | 25°-28° | 5 | 15 | 21 |
| GMP7208 | 7 | 25.4 | 27 | |||
| GMP7210 | 9 | 25.4 | 33 | |||
| GMP7212 | 11.4 | 25.4 | 41 | |||
| GMP7215 | 13.5 | 30 | 48 |
