沃拉斯頓偏光片
 |
 |
 |
 |
 ? |
| 材料： | a -BBO, Calcite, YVO4, Quartz | |
| 波長范圍： | a -BBO:200-3500 nm,Calcite:350-2300 nm,YVO4:400-5000nm,Quartz:200-2300nm | |
| 消光比： | Calcite, Quartz:<5x10 -5 ; a -BBO, YVO4:<5x10 -6 | |
| 并行性： | <1 arc Min |   |
| 表面質量： | 20-10 | |
| 光束偏差： | 典型值: <3', 高精度: <3" | |
| 波前失真： | λ/4@633nm | |
| 損壞閾值： | >500 MW/cm 2 | |
| 涂層： | Single MgF2 | |
| 安裝： | Black Anodized Aluminium | |
| Part No. | Extinction Ratio | Separation Angle(°) | C.A. Φa (mm) | O.D. Φ d (mm) | L±0.1(mm) |
| WSP6006 | <5x10 -6 | 15°- 27 °16°@800nm | 5 | 15 | 9 |
| WSP6008 | 7 | 25.4 | 11 | ||
| WSP6010 | 9 | 25.4 | 13 | ||
| WSP6015 | 13.5 | 30 | 18 | ||
| WSP6020 | 18 | 38 | 24 |
| Part No. | Extinction Ratio | Separation Angle(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1 |
| (mm) | |||||
| WSP7006 | <5x10 -5 | 16.7°-22.5°19°@980nm | 5 | 15 | 9 |
| WSP7008 | 7 | 25.4 | 11 | ||
| WSP7010 | 9 | 25.4 | 13 | ||
| WSP7015 | 13.5 | 30 | 18 | ||
| WSP7020 | 18 | 38 | 24 |
| Part No. | Extinction Ratio | Separation Angle(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1 | Unit Price |
| (mm) | ||||||
| WSP9006 | <5x10 -5 | 2°-3 °2°@1064nm | 5 | 15 | 14 | $149.00 |
| WSP9008 | 7 | 25.4 | 18 | $199.00 | ||
| WSP9010 | 9 | 25.4 | 22 | $249.00 | ||
| WSP9015 | 13.5 | 30 | 32 | $359.00 | ||
| WSP9020 | 18 | 38 | 44 | $539.00 |
| Part No. | Extinction Ratio | Separation Angle(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1 |
| (mm) | |||||
| WSP8006 | <5x10 -5 | 19.6°-23.3°20°@1550nm | 5 | 15 | 8 |
| WSP8008 | 7 | 25.4 | 10 | ||
| WSP8010 | 9 | 25.4 | 12 | ||
| WSP8015 | 13.5 | 30 | 16 | ||
| WSP8020 | 18 | 38 | 21 |
| Part No. | Extinction Ratio | Separation Angle(°) | C.A. Φ a (mm) | O.D. Φ d (mm) | L±0.1 |
| (mm) | |||||
| WSP9006 | <5x10 -5 | 2°-3 °2°@1064nm | 5 | 15 | 14 |
| WSP9008 | 7 | 25.4 | 18 | ||
| WSP9010 | 9 | 25.4 | 22 | ||
| WSP9015 | 13.5 | 30 | 32 | ||
| WSP9020 | 18 | 38 | 44 |
